収縮と反り – 冷却後の最終部品寸法を予測し、CADで金型形状補正を可能にします

エジェクタシステムの設計。自動運転の信頼性を確保するには、適切な排出が不可欠です。エジェクタの設計には以下のようなものがあります。

エジェクタピンアレイ：薄い部分や柔軟な部分ではなく、構造面を押し付けるようにサイズが決められている。

スリーブ式エジェクタ：コアを囲むように成形された部品用

剥離板：大きな平面または深いリブを持つ部品用

空気噴射：非常に薄い部品や壊れやすい部品向け

エジェクタピンのマーキング位置は、金型製作前に顧客の承認を得るために文書化されます。これにより、完成品に予期せぬ問題が発生することはありません。

金型製造工程の流れ

金型製造工程全体を社内で完結させる：

CAD設計と金型流動解析 – ゲート、ランナー、冷却装置、エジェクタの設計

CAMプログラミング – すべてのCNC機器の加工パスを生成します

粗加工 – 金型ベースから大量の材料を除去し、ブランクを挿入する

熱処理 – 必要に応じて（H13、8407はHRC48～52、S136はHRC50～53）

半仕上げ加工 – 最終寸法に近づけ、仕上げ加工用の材料を残す

EDM（必要に応じて） – 詳細な形状（鋭角な内角、狭いスロットなど）を作成

仕上げ加工 – 最終寸法と表面仕上げ

手作業による仕上げ／研磨／テクスチャリング – 必要な表面粗さまたはテクスチャ深さを実現する

金型組立 – すべての部品を取り付け、スライドとエジェクタの動きを確認する

金型試作（T0） – 射出成形機での最初の試射

検査およびCMM検証 – 完全な寸法レポート

T1/T2/T3の最適化 – 試験結果に基づいて必要に応じて改善する

摩耗試験（2,000サイクル） – 初期摩耗を促進し、状態を記録する

最終検査と認証が完了し、お客様の承認を待つ準備が整いました。

射出成形プロセスの最適化 – 効率とコスト管理

サイクルタイムの短縮。AnsixTechは、以下の方法でサイクルタイムを体系的に短縮します。

熱を素早く除去するためのコンフォーマル冷却チャネル

冷却水の温度と流量を最適化（入口／出口間の温度差ΔT

冷却時間を、部品の変形なく型から取り出すために必要な最小限まで短縮した。

金型開閉速度を最適化（高速接近、低速金型保護、高速閉鎖）

部品のクリアランスを確保しつつ、損傷を与えない程度の排出速度を設定

ロボットによる部品回収は、金型開口完了とタイミングを合わせて行われる。

エネルギー効率。全電動サーボマシンは、油圧式マシンに比べて消費電力が40～70%削減されます。急速加熱・急速冷却による金型温度制御（約8%の電力削減）と熱回収システムを組み合わせることで、部品1個あたりの設備全体のエネルギー消費量は業界平均を大幅に下回ります。

材料効率。ホットランナーシステムはランナーの廃棄物を完全に排除します。コールドランナー金型が避けられない場合は、再粉砕システムとクローズドループスクラップ管理により、顧客が承認した再粉砕率の制限に従って、ランナーの廃棄物を再利用可能な材料に戻します。

不良品の削減。クローズドループプロセス制御により、生産工程全体を通して部品が仕様範囲内に収まります。CpK値の高い用途では、部品間のばらつきが非常に小さいため、ほとんどの寸法で検査選別が不要となり、生産品の100%が工程内品質ゲートを通過できます。

品質管理および品質保証システム

AnsixTechの品質システムは、あらゆる段階で文書化された手順に従っています。

ステージ

品質活動

標準／ツール

入荷する原材料

MFI認証、水分テスト、色チェック

ASTM D1238、ISO 1133

生産

各シフトでの初回品検査、統計的工程図作成、サイクル完了時の100%目視検査

ANSI/ASQ Z1.4、独自のAIビジョンシステム

バッチ処理完了

最終記事の検査結果と最初の記事を比較する

CMM、光学コンパレータ

ロット出荷

分析証明書、寸法概要レポート、材料トレーサビリティ

ISO 9001:2015準拠

工程内SPCチャート作成。重要寸法をXバー管理図とR管理図にプロット。Cp値とCpK値を定期的に算出。管理限界値に近づくと対策を実施。

認証レベル。AnsixTechは標準でISO 9001:2015品質マネジメントシステム認証を提供しています。ご要望に応じて、IATF 16949（自動車関連用途向け機器部品の自動車グレードPPAP文書）、ISO 13485（医療機器用途向け機器部品の医療グレード文書）も提供可能です。

梱包と物流 – 迅速な配送実行

工場内梱包。部品は、自動コンベアまたはロボット梱包セルから直接、顧客指定の容器（トート、トレイ、箱、ゲイロードボックス）に梱包されます。梱包個数は、重量または画像認識による計数で確認されます。ラベルは顧客指定に従って貼付されます。

生産計画／在庫管理。MESはリアルタイムの生産進捗状況を追跡し、ジャストインタイム物流計画に十分な精度で完了予定日を予測します。顧客はAPIまたはレポートエクスポートを介してMESデータを自社の計画システムに統合できます。

物流モード。AnsixTechの出荷先：

航空輸送 – 金型輸送（大型工具、航空貨物）

海上輸送 – 大量生産部品の注文の場合、工場から仕向港までコンテナで輸送します。

陸路／鉄道輸送 – 国内施設からの地域配送

リードタイム：シンプルな金型：設計完了からT0試作まで10日間。中程度の複雑さの金型：25～45日間。量産部品の注文：金型キャビティ数、お客様のスケジュール、および物流方法に基づきます。AnsixTechは、注文受付時に書面による納品確認を提供します。

業界経験と信頼性の価値

28年以上にわたり家電製品の筐体製造に携わってきたAnsixTechは、幅広い分野にわたる豊富な経験を蓄積してきました。

*省スペース型電気製品（掃除機、バッテリー充電器）。大型白物家電（冷蔵庫、冷凍庫、洗濯機、乾燥機）。空調機器（エアコン、除湿機、扇風機、ヒーター）。小型キッチン家電（コーヒーメーカー、電気ケトル、ミキサー、フードプロセッサー、炊飯器、電子レンジ）。*スマートホーム制御パネル（タッチパネル、ディスプレイベゼル、センサーハウジング）。電動工具および園芸機器（握りやすい人間工学に基づいたハウジングおよびハンドルカバー）。

この深い理解により、AnsixTechは金型流動解析を開始する前に、材料の挙動パターン、ゲート感度、冷却挙動、部品形状のリスク要因を認識することができ、新しいアプリケーションごとに開発時間と試作ショットを削減できます。

概要 – 家電製品の筐体にAnsixTechを選ぶ理由

AnsixTechは、精密金型製造（0.002mm加工能力、50万～100万ショットの金型寿命）、豊富な射出成形能力（260台の射出成形機、30～2,800トン）、スマート製造（MES統合、AI画像検査、クローズドループプロセス制御）、プロセス安定性（温度差≤2℃、CpK≥1.33）、包括的な材料ポートフォリオ（UL94 V-0、UV安定性、エンジニアリング熱可塑性樹脂、LSRオーバーモールディング）、総コスト優位性（材料、プロセス、廃棄物の最適化による15～30%のコスト削減）、およびフルサービスサポート（DFM事前分析、サンプル試作、量産、組立、メンテナンス）を兼ね備えています。家電製品の筐体に関して、信頼できる長期的なフルサービスパートナーをお探しの顧客は、AnsixTechに連絡して、現在の製品設計の見直し、金型仕様の協議、DFMレビューとコスト見積もりを含むカスタマイズされた提案を受けてください。

本技術提案書は、AnsixTechの家電製品筐体金型製造、射出成形材料選定、スマート製造インフラ、プロセス品質管理、コスト削減手法、検証プロトコル、顧客価値提供における包括的な能力を網羅しています。具体的なプロジェクトに関するお問い合わせ、またはDFM（設計製造性）デモンストレーションの手配については、AnsixTechのエンジニアリングチームまでご連絡ください。

アンシックス・テック株式会社

家電製品用筐体に関するご計画がございましたら、いつでもお気軽にご連絡ください。お客様のアイデアを形にし、夢の実現をお手伝いし、市場からの大量受注獲得をサポートいたします。お問い合わせ先は info@ansixtech.com です。または、CTO の stephen@ansixtech.com までメールでご連絡ください。
